Industrial fan aRw

An industrial duct fan designed for public utility spaces such as shops, bars, restaurants, restrooms, as well as residential areas and industrial facilities like workshops, warehouses, and garages.

Ø 150

Ø 160

Ø 200

Ø 250

Ø 315

Ø 350

Description

Models and technical specifications

Documents

Description

Models and technical specifications

size	code	air flow	acoustic pressure	static acoustic	frequency voltage	motor power	rev.(1/min)	power consumption	max work temperature	gross weight	degree of protection	insulation class
150	01-106	180 m3/h	50 dB	35 Pa	230 V/50V, 50Hz	32 W	1400	0.2 A	40°C	1.6 kg	IP X2	1
160	01-101	185 m3/h	52 dB	32 Pa	230 V/50V, 50Hz	32 W	1400	0.2 A	40°C	1.7 kg	IP X2	1
200	01-102	400 m3/h	54 dB	52 Pa	230 V/50V, 50Hz	40 W	1400	0.25 A	40°C	1,9 kg	IP X2	1
250	01-103	1000 m3/h	56 dB	72 Pa	230 V/50V, 50Hz	86 W	1400	0,3 A	40°C	2,8 kg	IP X2	1
315	01-104	1350 m3/h	60 dB	82 Pa	230 V/50V, 50Hz	110 W	1400	0,4 A	40°C	3,8 kg	IP X2	1
350	01-105	1750 m3/h	66 dB	80 Pa	230 V/50V, 50Hz	110 W	1400	0,4 A	40°C	4,3 kg	IP X2	1
