Domestic wall fan pRemium
The pRemium domestic fan combines hybrid technology which ensures high aesthetic value, cleanliness and safety of use.
Ø 100 Ø 120 Ø 150
Available models:
It is connected via an electrical cube. It is a basic model and can be controlled by its own switch, for example, together with lighting
It is connected to a conventional socket via a plug and has a switch on a decorative cord.
The fan turns on when power is applied (e.g., on a switch shared with the light) and will work until the power is turned off plus for the time set on the controller. This works well, for example, after a bath, where moisture is still blown out after the user leaves the bathroom.
The fan requires a three-wire cable, as it is necessary to connect the control cable.
Has a humidity sensor, which the user sets in the range of 40 – 80%. The fan turns on when the set threshold is exceeded by bounds (e.g., when taking a bath) and runs until the humidity level is lowered plus about 3 minutes – to maintain the effect.
The fan requires a three-wire cable, as it is necessary to connect the control cable.
Very quiet airRoxy home fan from the pRemium family has a high-performance slide bearing. The turbine blades are specially shaped causing quiet and economical work. High-quality white plastic ensures the durability of the device, but also maintains aesthetic qualities. The slightly more pronounced grille of the front of the fan was inspired by the nature of the flowing air, it will be ideal not only as a bathroom fan, but also as an office or kitchen fan.
All our fans are equipped with thermal protection, which protects against overheating.
A back valve can be added to the fan to prevent reverse air flow.
| diameter | code | model | air flow | acoustic pressure | static pressure | voltage frequency | motor power | engine rpm (1/min) | protection degree | net weight | gross weight | pcs in package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 100 | 01-013 01-014 01-015 01-016 | S PS TS HS+TS | 104 m3/h | 1m 39dB 3m 38dB | do 35 Pa | 220-230V/ 50-60Hz | 15 W | 2400+-200 | IP X4 | PS 0,54 kg S/TS/HS ~ 0,45 kg | PS 0,63 kg S/TS/HS ~ 0,55 kg | 20 |
| 120 | 01-017 01-018 01-019 01-020 | S PS TS HS+TS | 158 m3/h | 1m 46dB 3m 44dB | do 35 Pa | 220-230V/ 50-60Hz | 16 W | 2200+-200 | IP X4 | PS 0,64 kg S/TS/HS ~ 0,57 kg | PS 0,74 kg S/TS/HS ~ 0,66 kg | 20 |
| 150 | 01-021 01-022 01-023 01-024 | S PS TS HS+TS | 257 m3/h | 1m 47dB 3m 45dB | do 21 Pa | 220-230V/ 50-60Hz | 20 W | 1450+-200 | IP X4 | PS 0,77 kg S/TS/HS ~ 0,70 kg | PS 0,88 kg S/TS/HS ~ 0,80 kg | 10 |
| [mm] | pRemium ø 100 | pRemium ø 120 | pRemium ø 150 |
|---|---|---|---|
| A | 160.5 | 180 | 210 |
| B | 113 | 113 | 113 |
| C | 100 | 120 | 150 |
| D | 85 | 85 | 85 |
![](/wp-content/uploads/2024/01/prim-TS-connect-1-1024x549.webp")
A back valve can be added to the fan to prevent reverse air flow.
