Domestic fan pRestige
Fans from pRestige family are axial wall fans with innovative design inspired by cubistic, universal shape of a square. Those fans were designed for economics and ecology purpose. They are equipped with a gravity shutter, which blocks the reverse airflow without additional energy consumption. pRestige fans are the best choice for rooms with high humidity level.
Ø 100 Ø 120 Ø 150
Available models:
connected via an electrical cube to the basic model and can be activated using its own switch, for example, together with the lighting
connected via a plug and is switched by decorative chain
The fan turns on when power is applied (e.g., on a switch shared with the light) and will work until the power is turned off plus for the time set on the controller. This works well, for example, after a bath, where moisture is still blown out after the user leaves the bathroom.
The fan requires a three-wire cable, as it is necessary to connect the control cable.
Has a humidity sensor, which the user sets in the range of 40 – 80%. The fan turns on when the set threshold is exceeded by bounds (e.g., when taking a bath) and runs until the humidity level is lowered plus about 3 minutes – to maintain the effect.
The fan requires a three-wire cable, as it is necessary to connect the control cable.
has a motion sensor that activates the fan when it senses the user’s presence and runs for a specified time.
The fan requires a two-wire cable.
The exceptionally quiet airRoxy home fan from the pRestige family, in white color, features high-quality sleeve bearing. Its characteristic feature is the geometric motif on the front, where gravity blinds are located. The slats move ‘inward’ into the device, allowing airflow in only one direction – exhaust. This protects interiors from so-called drafts – unwanted cold and external dirt. The turbine blades are shaped to ensure quiet and economical operation. High-quality material ensures the device’s durability while maintaining aesthetic values. All our fans come with thermal protection to safeguard against overheating.
Fans from the pRestige family are the best choice for rooms with excessive humidity accumulation.
A back valve can be added to the fan to prevent reverse air flow.
| średnica | kod | wersja | wydatek powietrza | ciśnienie akustyczne | ciśnienie statyczne | napięcie zasilania | moc silnika | obroty (1/min) | stopień ochrony | waga netto | waga brutto | opak. zbiorcze |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 100 | 01-025 01-026 01-027 01-028 01-029 | ZG S ZG PS ZG TS ZG HS+TS ZG MS | 104 m3/h | 1m 39dB 3m 38dB | do 35 Pa | 220-230V/ 50-60Hz | 15 W | 2400+-200 | IP X4 | PS 0,58 kg S/TS/HS/MS ~ 0,49 kg | PS 0,67 kg S/TS/HS/MS ~ 0,60 kg | 20 |
| 120 | 01-030 01-031 01-032 01-033 01-034 | ZG S ZG PS ZG TS ZG HS+TS ZG MS | 158 m3/h | 1m 46dB 3m 44dB | do 35 Pa | 220-230V/ 50-60Hz | 16 W | 2200+-200 | IP X4 | PS 0,69 kg S/TS/HS/MS ~ 0,62 kg | PS 0,79 kg S/TS/HS/MS ~ 0,70 kg | 20 |
| 150 | 01-035 01-036 01-037 01-038 01-039 | ZG S ZG PS ZG TS ZG HS+TS ZG MS | 257 m3/h | 1m 47dB 3m 45dB | do 21 Pa | 220-230V/ 50-60Hz | 20 W | 1450+-200 | IP X4 | PS 0,87 kg S/TS/HS/MS ~ 0,79 kg | PS 0,96 kg S /TS/HS/MS ~ 0,89 kg | 10 |
| [mm] | pRestige ø 100 | pRestige ø 120 | pRestige ø 150 |
|---|---|---|---|
| A | 160,5 | 180 | 210 |
| B | 117 | 117 | 117 |
| C | 100 | 120 | 150 |
| D | 85 | 85 | 85 |
![](/wp-content/uploads/2024/01/prim-TS-connect-1-1024x549.webp")
A back valve can be added to the fan to prevent reverse air flow.
